Bosch PPM9A6I40, Gas hob
£655.00
Awaiting Stock
02922741179 for Availability
02922741179 for Availability
- Warranty 2 Years
- ColourBlack
- Heating Zones5
- Hob Width81 - 90cm
Design
- Tempered glass surface, Black
- frameless design: install the hob either flush or slightly raised on the worktop
- Cast iron pan supports with rubber feet
- FlameSelect: precisely control and adjust the flame in nine defined levels.
- Design co-ordinated control dials, front: easily access dials in front with strong grip for effortless turning.
- Ignition via control dials: just push and turn the dials to ignite the flame.
- 5 gas burners:
- Left: wok burner up to 4 KW (depending on gas type)
- Center front: economy burner up to 1 KW (depending on gas type)
- Center rear: standard burner up to 1.75 KW (depending on gas type)
- Right rear: high-speed burner up to 3 KW (depending on gas type)
- Right front: standard burner up to 1.75 KW (depending on gas type)
- Removable control dials for easy cleaning between knobs.
- Dishwasher suitable pan supports for easy cleaning.
- Cast iron pan supports with rubber feet: little weight and compact form, yet high stability due to continuous surface.
- Flame failure safety device: prevents unwanted gas flow when flame goes out.
- Usable for: Nat gas L/LL G25/20mbar(DE)
- NG H/E 20mbar, E+ 20/25mbar Natural gas H 25 mbar (HU) Natural gas L 25 mbar (NL) Liquid gas G30,31 28-30/37mbar Liquid gas G30 37 mbar (PL) Liquid gas 50 mbar
- Pre-set for natural gas
- Nozzle set for LPG jets included. Connection to 28-30/37 mbar bottled gas. Nozzles for all other gas types can be ordered via the customer service. For nozzle change, please contact the customer service.
- Dimensions of the product (HxWxD mm): 54 x 915 x 520
- Required niche size for installation (HxWxD mm) : 45 x 850 x (490 - 500)
- Min. worktop thickness: 20 mm
- If installed flush, minimum worktop thickness is 30mm.
- Power cord: 1 m
- Connected load: 11.5 KW
| Manufacturer | Bosch |
|---|---|
| GTIN | 4242005496242 |
| Model Number | PPM9A6I40 |
| Hob Width | 81 - 90cm |
| Heating Zones | 5 |
| Colour | Black |
| Warranty Duration | 2 |
| Type of Control / Appliances | Mechanical |
| Type of Control Settings | Knob |
| Construction Type | Built-In |
| Installation Type | Built-In |
| Safety Features | Flame failure safety device for each burner |
| Energy Input | Gas |
| Appliance Current (A) | 3 |
| Appliance Voltage (V) | 220-240 |
| Appliance Frequency (Hz) | 60; 50 |
| Plug Type | no plug (electrical connection by electrician) |
| Cord Length | 100 |
| Min Niche Height | 490 |
| Max Niche Height | 500 |
| Min Niche Width | 850 |
| Max Niche Width | 850 |
| Niche Depth | 45 |
| Cooker / Oven Control Panel Location | Front |
| Cooker / Oven Time Options | No delay options |
| Fuel Type | Nat gas H/E/(L) 20 (25) mbar |
| Alternative Fuel Type | Liquid gas G30,31 28-30/37mbar |
| Type of Lid | Without |
| Type of Safety for Gas | Electromagnetic for each burner |
| Residual Heat Indicator Type | Without |
| Number of Gas Burners | 5 |
| Ignition System | Yes |
| Type of Frame | For a flush or slightly raised built-in solution. |
| Colour of Frame | Black |
